Online Wind Turbine Challenge

My project is a 6-bladed wind turbine made out of cardboard, hot glue, and dowels. I worked to build it in my school's design and energy class, and it took me a few sessions of 40 and 30 minutes to construct. It produces 5.22 volts, meaning that it can power LED lights and USB chargers.

Our turbine has six blades with two different designs. Each blade is rounded with a flatter bottom. The smaller blades have a pointed end while the larger blades have a huge rounded end.

The project is made out of 3 curved carboard blades. We attached a wooden stick to the ends of the blades to stick it into the circular disk that acted as a foundation when we tested the blades.

Our Wind turbines have 6 blades. They resemble the shape of a knife. They have a slight angle and are made out of cardboard.

We decided to go with a hook design so it would catch more air and push the blades faster. It also looks fancy.

We created a windmill. We made 4 blades out of carboard. And we created it.

It has three turbines. Made with cardboard, glue, and sticks

Our turbine uses 6 blades. Our project is unique because on one side the blade is straight, and on th eother it's curved. Our gets 4.5 volts of energy

Our turbine uses 6 blades. Our project is unique because on one side the blade is straight, and on th eother it's curved. Our gets 4.5 volts of energy

This is a wind turbine with 6 blades. It is designed for wind turbine power. We used 6 blades for more speed to produce more wind.

Our wind turbine has four blades. The blades are relatively short. The blades are straight at the top, then they round at the bottom.

This project was made in Sustainable design and Energy. We made this with cardboard, glue, and a fan. We have worked on this project for 4 days.

The wind turbine project helps to understand how wind turbines work and their mechanics. It explains the factors that affect the speed of the wind blades. It also explains how wind turbines generate energy

The project was to show our understanding of wind energy and wind turbines. We had to make blades for wind turbines, and we had to make them using our knowledge of wind. So far, we have one of the highest voltages in our class with a voltage of 1.75v.

This project is about experimenting with blades design to build a wind turbine that generates the most energy. We tested two different blades with different designs, pitch, and materials. We then recorded the blade design that was used, the number of blades used, the blade pitch, the radius, the area of the rotor swept, the resistor, the wind speed, the voltage, and the power.

Project Description: We created a wind turbine to see which design will help the world to produce the most energy. We used different materials to see which one was the best to use, as well as different pitches. Each table conducted their own experiments to collect their data.

This project is about experimenting with blades design to build a wind turbine that generates the most energy. We tested two different blades with different designs, pitch, and materials. We then recorded the blade design that was used, the number of blades used, the blade pitch, the radius, the area of the rotor swept, the resistor, the wind speed, the voltage, and the power.

We did the project something like this, we had to do was create two blade designs and states the material of the blade. Then we test our blade design and note down Number of blades, Blade pitch, Radius, Rotor swept area, Resistor, Wind speed, voltage and power. Finally, We type the data in a word document and finish the project in kid wind.

The purpose of this project was to figure out which design can build a wind turbine that generates the most energy based on pitch, material, and shape. The best pitch was 30 degrees. The best material was cardboard, and the best shape was curved.

This windmill had a rectangular base made from PVC pipes. This base provided support for the windmill tower, motor, and blades. The blades were made from cardboard taped to wooden dowels, the windmill tower was made from PVC pipe, and the motor was made from a router and plastic.

The windmill blades are made out of cardboard, hot glue, and wood sticks. The base is plastic with wires that connect to a battery. Also there is a circular device that holds the blades.

In this project, the green machine, I built and tested blades, gears and a more stable base. I explored a 12 blade cardboard design and added another gear to the gearbox. The base was made more stable by adding screws that connected to the tower supports.

PVC was used to create the turbine and to hold everything together. 3 blades in the shape of goldfish were made. The optimal pitch was found to be 70 degree angle.

My classmates and I worked with different materials. We also worked with different types of gears. We tried 2 gears, 4 gears and then finally 3 gears.

We started with small blades then moved to bigger and thicker blades. The group modified the blades to go faster. We tried to use double gears but it was slowed down. The blades used measured a solid 6 Joules.

Our group started out using a bunch of tiny blades which failed. Then we switched to a fish shaped blades which worked out ok. We experimented with different pitches and decided on a pitch of 10 degrees.

The 6 blades look like bird wings. The optimal pitch was 5 degrees. We used a PVC stand with 4 gears: a 32:8 and 64:8.

Our wind turbine was composed of the kidwind vernier set, 3d printed blades, gears reused from our school, and wooden dowels. Decorated using acrylic paint, modge podge, and vines. Our main design was based off the offshore turbines that were being proposed in Maryland incorporating designs surrounding nature and water.

Our wind turbine was composed of the kidwind vernier set, 3d printed blades, gears reused from our school, and wooden dowels. Decorated using acrylic paint, modge podge, and vines. Our main design was based off the offshore turbines that were being proposed in Maryland incorporating designs surrounding nature and water.

The project is meant to represent our school. The project is meant to represent our school mascot. The project is meant to symbolize the meaning of our school.

Our blade type is a rectangle with a slant on the side of the blade with a flat top. We started with three blades, but then we changed to four blades because it created more energy. Our gear ratio is a big 64-tooth gear with a small 8-tooth gear, because we realized this ratio created more energy than our other ratio (32-thooth and 16-tooth). We used corrugated cardboard for the blades and hot glue and tape to attach the dowels to the blades.

As a team we came together and decided to fabricate our wind turbine from scratch. We used an aluminum base as well as steal conduit for a tower then we used PVC thin walled sewer pipe for our blades.

We assembled the base. Then we grabbed a pipe and plugged it into the base. After that we took the shaft holder and screwed it in place. We put the shaft into the holder and put on the gears. We then took wood and made propellers and tested them.

Our turbine has gone to competition at TSTC and Texas Tech and placed 2nd at both. Our base was cut in house by our CNC machine from aluminum sheet metal and our tower was recycled from a steel conduit. Our blades were cut and heat molded from a PVC pipe.

Our turbine consists of blades made of chemical totes, a base built out of wood, and our 32:1 gear ratio is made with KidWind gears. We ran into problems with spacers creating too much friction, so we used metal washers to eliminate the friction.

This was a 3D printed wind turbine project to determine the most optimal blade shape for KidWind Wind Turbine projects. Three sets of blade shapes were made: triangular, rectangular, and cambered. The cambered blades produced the most Joules.

We use a gear box and our blades are made of a lightweight foam. We chose a shape to model an airplane wing to assist with lift. We weighted our blades to ensure all our blades are the same weight.

We are ninth grade HS wind team looking to improve on out middle school KidWind turbine design. Our upgrades to our turbine include: sturdy table base, perfectly centered hub and using 3D printed airfoils instead of flat blades at 2024 VA State competition. After trial and error, we were able to find the perfect gear ratio 72:1.

We created a turbine with a wood base. The blades are 22 inches long and made from used chemical totes that we found on a family farm, they are attached to a nose cone that one of our teammates 3D-printed. We used KidWind gears and have a 32:1 gear ratio. We struggled with spacers on the gearbox but were able to fix them with metal washers.

We created blades that were shaped similar to an airplane wing with a few adjustments. We chose a lightweight foam material and we use a gearbox for maximum efficiency. We created a slide presentation of documentation of all of our work.

This project is a KidWind Wind Turbine designed to generate electricity from wind energy. It features a small, efficient turbine that captures wind and turns it into power. The goal is to demonstrate how wind energy can be used in everyday life to create clean, renewable energy.

This project involves building a KidWind wind turbine to harness wind energy and convert it into electricity. The turbine will be tested to see how well it generates power from wind. It helps demonstrate how renewable energy works in real life!

In the beginning we had many different problems like our fan blades being too weak,lack of wind speed, etc. After we figured out the problem with our fan plans we changed them to a strong wood material, instead of the cardboard fan blades we used before, which made the power stronger, and the fan started working better. We went from being last in every category in our class to being first in most of them after we switched our fan blades, the fan blades were our
only problem as everything else was built great

In the beginning we had many different problems like our fan blades being too weak,lack of wind speed, etc. After we figured out the problem with our fan plans we changed them to a strong wood material, instead of the cardboard fan blades we used before, which made the power stronger, and the fan started working better. We went from being last in every category in our class to being first in most of them after we switched our fan blades, the fan blades were our
only problem as everything else was built great

Accomplished in four days with no prior experience and knowledge with wind turbines.
We learned how the shape and the degree of the blade can affect how strong the voltage can get.

We assembled the base. Then we grabbed a pipe and plugged it into the base. After that we took the shaft holder and screwed it in place. We put the shaft into the holder and put on the gears. We then took wood and made propellers and tested them.

After setting up the stand, we decided to use wood for the blades because its more sturdy than paper, but lighter than cardboard. We made sure the blades were close to the turbine. We also tested out other methods of making more energy.

Our project was small, not very heavy blades that could move quickly when they catch wind to generate more energy. They look as if they slice through the air, but catch the air and take it along with the blade in the circular motion. We chose three blades after testing that they move quicker and generate more energy than six blades.

Our turbine is set at a 5° pitch. There is three blades, each 20 cm long 4.5 cm wide. Each blade is about 0.24 oz (6.7 grams)

The blades are 9 inches long. 3 blades on windmill. Cardboard glued with hot glue, two layers of cardboard.

We made a wind turbin. We built this because we wanted to see if it would produce energy. We made our wind turbin out of cardboard.

It has 6 blades. The blades are kind of short and skinny. It is made out of cardboard and hot glue.

It is made of cardboard. The wings are each about 26 cm long.The blades are angled at 20 degrees.

This turbine made by the Zepher Crusaders has a 1:16 gear ratio and produces 20-30 volts at low wind speeds. The blades are 3D printed airfoils with shrink-wrap over them to make the shape. The base is made from PVC pipe and a board that was found on the curb.

This turbine made by the Zepher Crusaders has a 1:16 gear ratio and produces 20-30 volts at low wind speeds. The blades are 3D printed airfoils with shrink-wrap over them to make the shape. The base is made from PVC pipe and a board that was found on the curb.

3 to 4 blade windmill built myself. I built this myself using tape hot glue. The cardboard needed hot glue

3 to 4 blade windmill. I did the regular design for it. Everything is good

3 to 4 blade windmill I built myself

Ratpile has 3 blades that are shaped like the wings of an airplane. The central pole is supported by 2 ropes of tape. The base is wide so it can push against the wind.

The wind turbine we created is made from PVC pipes card board, tape, hot glue, and dial rods. We tried different types of blades like A very light type of wood, card board and now thin sheets of card board. We have also tried three different bases but now we finally found the one.

The KidWind project allowed us to find a way to produce renewable energy in a simulated environment. We were tasked with creating a wind turbine that would put out as much electricity as we could get it to. We used different prototypes and blade angles to reach the maximum amount of energy output.

The project is a shorter six-winged gold and black demon. This particular individual was faster than a track hawk. Some say you can hear the hemmy winding up when it goes.

Our blades have the shape of an airplane's wing to be able to cut through the air. Ropes of tape support the central pole.

Our blades have the shape of an airplane’s wing to be able to cut through the air. Ropes of tape support the central pole.

Our windmill has 3 blades made out of balsa wood. The blades have an aerofoil shape, and the central pole is braced with tape. The base is wide to be able to push against the wind

We are a middle school tech class exploring energy

Team Jogan was tasked with building a windmill. After countless designs, materials, and attempts, we had found a good design. We spent each class period working to find the best solution..

Our project is very sturdy and has a simple design. It has 6 blades and different sizes and shapes. It was an easy and good project for our first time at this.

This project created a great way to learn about the wind power energy. As partners, we had a lot of fun trying to figure out new ways to make energy faster and more efficient. Overall, we think this project was a fun learning experience.

Plywood taped to cardboard that is taped to a peg, then placed into the motor of the turbine.

It's very time consuming. Some of the parts are very fragile. Its also on the taller side, reaching up to 3 1/2 ft tall!

It’s very time consuming. Some of the parts are very fragile. Its also on the taller side, reaching up to 3 1/2 ft tall!

We made this shorter. This made it so it was level with the fan allowing us to produce more electricity. The only downside to this is we can't have huge blades to catch the wind. We solved this problem by changing the shape of our blades. to a shape that isn't huge but still catches the wind.

We made this shorter. This made it so it was level with the fan allowing us to produce more electricity. The only downside to this is we can’t have huge blades to catch the wind. We solved this problem by changing the shape of our blades. to a shape that isn’t huge but still catches the wind.

Plywood taped to Carboard that is taped to a Peg, then placed into the motor of the Turbine.

This project was to strategically construct a windmill that optimizes space to produce the most energy. We did this by constructing 4 blades at certain angles to catch the wind. With a strong base able to withhold the fans' power.

This project was to strategically construct a windmill that optimizes space to produce the most energy. We did this by constructing 4 blades at certain angles to catch the wind. With a strong base able to withhold the fans’ power.

This was created during a training event. I think my students will have fun!

This windmill works by taking the air that hits it and using that to spin the blades. The blade is cut and put to a certain angle to catch the wind. This makes the rotor spin leading it to create energy.

Our project consists of 3 cardboard turbines which are attached to the Kid Wind generator. We then use a fan and angle our blades to get the maximum output voltage.

We were inspired by a fan. We engineered our blades like fan blades but added some of our own design into it too. We cooperated with each other.

My project is a wind blower. This creates win.

The team started out using a bunch of tiny blades which failed. Then the team switched to Swedish candy fish blades which worked better. The team experimented with different pitches and decided on 10 degrees.

This project was very hard to complete. It required extraordinary dedication from my team, as well as a lot of outside research on airfoil design. In the end, we finalized our design and beefed up the components to handle the excess stress.

This is a wind turbine prototype that aims to combine proven research-based features with twists of innovation. The project used PVC blades that are airfoiled and spaced at 10 degree pitch The hub is custom-made using aluminum material. The base used PVC pipes and structured to attain optimum stability. The gearbox used a 32 to 1 compound gear ratio. Below is a video link:

The objective of the project is to design and build a wind turbine prototype that generates the most power. The turbine used PVC blinds for blades and PVC pipes for the base. The gear mechanism uses a compound gear ratio of 32 to 1, which means that as the driver gear spins, the final driven gear spins 32 times faster thereby generating more power. After a series of iterations, below is a video of the final project (copy paste to view):

For the challenge we where given a KidWind Advanced Wind Experiment Kit by our teacher. Our group of 5 started off by designing multiple different versions of blades on Whitebox Learning. In the end we settled with a 400mm blade with a Somers S102 airfoil because of the lift drag ratio.

For our wind turbine project, our group of four started on WhiteBox Learning, researching wind turbines then moving to the programs engineering section to design blades. We first tested wooden balsa wood blades, then determined our 3D printed blades to be better and installed them. We ran our final tests and took photos and videos with them.

We designed, built, and tested a wind turbine made from PLA plastic. The turbine features 3D-printed blades shaped like long triangles. The project focuses on making the design more efficient and improving energy production.

Our project idea was to create an efficient, easy-to-make turbine. We created an arc on our blade to pick up the wind like an airplane wing or prop. We want to make wind power simple and easy to access, and we believe that this design attests to that.

I made six blades out of wire. They are not flat, so that the turbine can spin easier. I wrapped tape in between the wire frames.

we have a wind terbine. This has 3 blades with fether shaped blads. This is vary light

We made this out of scrap cardboard. Tools that we used include sanders, scroll saws, handsaws, and filers. Max Megawatts is 90.6

My project is a turbine and it has 3 sides and it spins good

This wind turbine has three blades.

It's a three blade turbine with a inward bending shape on each balde.

bird

my project has 4 blades and it is made out of cardboard with wooden sticks attached to it.

Six blade wind turbine with hand-carved tubercles on leading edges and curved polyester/paper trailing edges. Tubercles improve airflow over blade. The poly/paper reduces weight and is curved. It flexes to reduce drag.

Homemade wind turbine out of recycled materials. Wooden base and tower to provide stability. Drive shaft made of LEGO gears.

its a three blade turbine. it has 29 cm long blades

We made a kinda half circle shape with a little curve in it. and then we put a carboard piece in the middle so it could be stable not floppy. After that we pu sticks to insert the propeller in the clamp things.

Our blade's are shaped like peanuts. They are made out of cardboard and there are popsicle sticks on the back for support.

we are a middle school hoping to learn more about renewable energy.

it is a wind turbine design. we made it out of map board. we are trying to see if it is better than the turbines right now

Our project is fast, stable and can be very efficient. We are very proud of this project and we hope it can help you on your way to more sustainable energy. Thank you!

We made a wind turbine with 28 cm blades. There were 3 blades and were each shaped like a butter knife. We made them out of cardboard and glued straws on the back to put in the hub. We then stuffed them with paper so they wouldn't get squashed and rapped masking tape around the ends so it would stay in the hub. When we first tested our turbine, it couldn't spin because the blades were too long. We then made some adjustments and our final test went great!

we did the wind turbine

Middle School Engineering Class

My project is a three blades diamond design of a wind turbine.

The project was built by 2 people shane gerber and carter cetroni. the project took a while to get all the data but we came to mabey win

My project is a rectangular wind turbine. this turbine has a perfect shape for a wind turbine.
